02" Rugged Density Red Meter 2" / 50.8mm

02" Rugged Density Red Meter 2" / 50.8mm

Estimated Weight and Dimensions:
WOODEN CRATE @ 41"X22"X30" (ID's 38x18x23.25 Top Screwed) Meter 192.5lbs approx. Meter and Crate 308lb approx.

Installation Orientation | Horizontal Alignment Required:
All Red Meters must be installed in a horizontal orientation, with a tilt of no more than 15 degrees from level. This ensures accurate performance and long-term durability of the system.

Power Requirements | Standard Power Supply:
Red Meters operate on 120V AC as standard. If your site requires a different voltage configuration, please indicate so — upgrades can be accommodated upon request.

Liner Material Options | Standard Liner – Linatex
All Red Meters are equipped with a Linatex liner as standard, selected for its durability and compatibility with a wide range of industrial applications. Upgrades Available. Alternative liners are available and can be specified based on your unique process requirements, including: Media type, Operating pressure, Temperature range, Chemical compatibility etc. If your application requires a different liner material, please contact your Business Development Manager (BDM) for guidance on available options and material recommendations.

Vacuum Conditions | Important Operational Note:
Red Meter products are not compatible with vacuum conditions (i.e., negative pressures below 0 psi). For optimal performance and to avoid damage or failure, we strongly recommend the installation of a vacuum relief valve if any vacuum is present in your process line. Disclaimer : Red Meters is not responsible for performance issues or damage resulting from vacuum exposure if a relief valve is not installed.

Mating Flange Type | Standard Flange:
All Red Meters are supplied with ANSI 150 mating flanges as standard. Alternate flange types and sizes are available upon request. Please specify your requirements during the estimate process. Note: Custom flange selections may be subject to additional costs depending on size, material, or specification changes.

Crating & Packaging | Crate Included:
Each Red Meter order includes a durable ISPM 15 stamped wooden crate, built to meet international shipping standards. Crating covers both parts and labor, ensuring your unit is securely packed and protected during transport. Crates are suitable for both domestic and international freight requirements.

Installation Documentation | Installation Guides Available:
Installation instructions are available for all Red Meter models. These guides ensure proper setup and integration into your system. Please request the appropriate guide if needed or consult your BDM for assistance.
