05" Rugged Density Red Meter 5" / 127mm
+4
+3
+2

05" Rugged Density Red Meter 5" / 127mm

Store / Rugged Density Red Meter
$23,833.10
Specs
End User
Enter your text
Geographical Location of the Installation
Enter your text
Operational Location (where in your system will the Red Meter be fitted)
Enter your text
Summarize Your Application
Enter your text
Industry
Pipe Size Unit of Measurement
Do you need another type of Mating Flange ? Please explain, this may be subject to a price change TBA
Enter your text
Media Description
Enter your text
Pressure above 300 PSI / DIN 20 please specify
Enter your text
Slurry pH
Enter your text
Density Unit of Measurement
Dry Solids Density or SG
Enter your text
Carrier Liquid Density or SG
Enter your text
Do You Have Power Onsite?
Do you need another type of Power ? Please explain, this may be subject to a price change TBA
Enter your text
What's your expected delivery date?
Please choose a date
Anything else you would like to tell us?
Enter your text
Installation Guide
Estimate requested by Name
Enter your text
Your Company
Enter your text
Your Telephone
Enter your text
Your Email
Enter your text
You are a / an
In stock
Product Details
Brand: Red Meters

05" Rugged Density Red Meter 5" / 127mm

Estimated Weights and Dimensions: WOODEN CRATE @ 41.375”X22”X32” (ID’s 37.6.25x18x25.25, Top Screwed) 261lbs approx. 411lb approx.

Installation Orientation | Horizontal Alignment Required:
All Red Meters must be installed in a horizontal orientation, with a tilt of no more than 15 degrees from level. This ensures accurate performance and long-term durability of the system.

Power Requirements | Standard Power Supply:
Red Meters operate on 120V AC as standard. If your site requires a different voltage configuration, please indicate so — upgrades can be accommodated upon request.

Liner Material Options | Standard Liner – Linatex
All Red Meters are equipped with a Linatex liner as standard, selected for its durability and compatibility with a wide range of industrial applications. Upgrades Available. Alternative liners are available and can be specified based on your unique process requirements, including: Media type, Operating pressure, Temperature range, Chemical compatibility etc. If your application requires a different liner material, please contact your Business Development Manager (BDM) for guidance on available options and material recommendations.

Vacuum Conditions | Important Operational Note:
Red Meter products are not compatible with vacuum conditions (i.e., negative pressures below 0 psi). For optimal performance and to avoid damage or failure, we strongly recommend the installation of a vacuum relief valve if any vacuum is present in your process line. Disclaimer : Red Meters is not responsible for performance issues or damage resulting from vacuum exposure if a relief valve is not installed.

Mating Flange Type | Standard Flange:
All Red Meters are supplied with ANSI 150 mating flanges as standard. Alternate flange types and sizes are available upon request. Please specify your requirements during the estimate process. Note: Custom flange selections may be subject to additional costs depending on size, material, or specification changes.

Crating & Packaging | Crate Included:
Each Red Meter order includes a durable ISPM 15 stamped wooden crate, built to meet international shipping standards. Crating covers both parts and labor, ensuring your unit is securely packed and protected during transport. Crates are suitable for both domestic and international freight requirements.

Installation Documentation | Installation Guides Available:
Installation instructions are available for all Red Meter models. These guides ensure proper setup and integration into your system. Please request the appropriate guide if needed or consult your BDM for assistance.
